Q(D)Series multistage submersible electric pump

QD, Q, QY type oil submersible pump (hereinafter referred to as the pump, water pump, motor) sealed by three parts, pump water pump located on the upper level or single stage centrifugal impeller, radial diffuser structure; pump motor is located in the lo

The pump should be able to work normally under the following conditions:
1 medium temperature not exceeding +40;
2 medium pH value between 6.5-8.5;
3 medium containing solid impurity volume of not more than 0.1%, the particle size is not greater than 0.2mm;
4 power supply frequency is 50HZ, voltage for single-phase AC 220V, three-phase AC 380V, voltage fluctuation range of 0.9-1.1 times the rated value;
5 diving depth of not more than 5m.

performance parameter
