Typical Applications

Water supply
Sprinkler irrigation
Pressure boosting
Fire-fighting

Operating conditions

Minimum well diameter:4"
Maximum fluid temperature up to +35° C
Maimum sand content:0.25%

Specification:

Rewindable motor or fully enclosed
shielding motor
Single-phase: 220V-240V/50Hz
Three-phase:380V-415V/50Hz
Dimension complied with NEMA standard
Curve tolerance accord with ISO9906

Options om request

Special material components
Start control box or automatic digital control box
Cable length
Other voltages of requency 60Hz
Single phase motor with built-in capacitor
