Application

Suitable for use in civil and agricultural applications.The high
effciency and continuous duty capabilities makes these pumps
ideal for use in activities such as flood and spray irrigation,gardening,
agriculture ,drawing water from lakes,rivers and wells ,or
for industrial applications where characteristics of high head and
mid flow rates are required.

Component Construction

Pump body: Cast iron
Motor housing:AISI304 SS
Impeller:PPO or cast aluminium
Motor shaft:Carbon steel,AISI420/304 SS if request
Mechanical seal:Ceramic/Graphite
Screw and bolt: Stainless steel
Cable length:7m with plug , other lengths optional

Motor

Two-pole induction motor (n=2850 r.p.m)
Insulation Class B
Protection IP68
Continuous service S1
Thermal protector for single phase

Operating conditions

5m maximum immersion depth
Liquid temperature up to 35℃
Maximum ambient temperature 40℃
